DIY Digital Storage Oscilloscope

Overview

[Add your project overview here]

Features

• [Feature 1]
• [Feature 2]
• [Feature 3]

Technical Details

• Intel Altera EP1C3T100C6 Cyclone FPGA
  • 2910 Logic Elements, 52KB RAM, 65 I/O
• Texas Instruments ADS5204
  • Low power, Dual 10-Bit, 40MSPS ADC
  • With PGA with gain of 0dB to 18dB (= linear gain of 0 to 63)
• Texas Instruments DAC7821
  • 12-bit, Parallel Input DAC
  • 10MHz BW, 20.4 MSPS update rate
• FTDI FT232R USB to UART Bridge
  • 3.3V, 5V tolerant
• Analog Devices AD8066 Dual Opamp
  • 145 MHz FastFET
• Analog Devices LMH6644 Quad Opamp
  • 130MHz, 75mA Rail-to-Rail Output
